[2-071 m.tec]

m.tec. Swinghandle

ICON_IP65
ICON_ROHS
ICON_DIN_61373
ICON_TUERANSCHLAG_LR
ICON_RUNDSTANGE
ICON_MAGNETTECHNIK_SCHWARZ

Advantages

  • Low profile design.
  • High locking security.
  • Tamper-proof.
  • Vibration-proof according to DIN EN 61373.
  • IP65 according to DIN EN 60529.

Material

  • Swinghandle: zinc die, powercoated, black
  • Key: PA, black

Remarks

door thickness 1-3mm

a) keyed different incl. 1 key
b) key alike without key, please order key c) separately
Further keys on request.

Attention: H-dimension of the cam not less than 12mm!

1.) rotating bottom for RH/LH
2.) sealing inside the door

Please select version Product data sheet
