Rod Latch for Multi-Point Locking FS PrC

ICON_ROHS
ICON_TUERANSCHLAG_LR
ICON_FLACHSTANGE
ICON_CUTOUT_PR_C
ICON_DIRAK_GEERDET
3_170
E_3-170_1
E_3-170_2
3_170
E_3-170_1
E_3-170_2

Advantages

  • Rod latch for mounting outside the sealed area.
  • For Cutout C.
  • Flat rods 14x3mm with mounted dual rollers.
  • Dual hooks provide compression.
  • By rotating around the longitudinal axis RH / LH application.
  • Suitable for inserts and escutcheons, wing knob, L-handle or swinghandle.
  • Grounding with grounding clip (optional).

Material

  • Rod latch: zinc die
  • Rods: steel, zinc plated
  • Dual rollers: brass

Remarks

Version a) one-piece - 2 latching points.
Version b) three-part (lock with quick fastening and two rods) - 4 latching points.

1. stroke 24mm
2. open position
3. closed position

Attention: if the rod guide 208-1523.54 is used the weld stud has to be moved 2mm inwards!

Selected version

Product number 208-9108.00-00000
Delivery Unit: 1 pc.
Installation type: screw-on
Total dimension extended: 1850
Dual rollers B: 850
Dual rollers A: 275
Locking points: 4
Door height Th: 1900 mm - 2200 mm
Name: Rod latch, 3-parts
CAD model
Remove selection Product data sheet
